OPERATING TECH OTE-4824 AC ADAPTER 24Vdc 2A 4Pin [: :] Molex USE
larger image
Model: OPERATING TECH OTE-4824 AC ADA
0 Units in Stock
Ask a Question
$43.14
Buy More,Save more.Need a large quantity?
email us
for a special quote.
Quantity
Discount Price
3 - 9
$40.98
10 - 19
$39.26
20 - 49
$37.53
50 - 149
$36.24
150 +
$30.89
Sold Out
OPERATING TECH OTE-4824 AC ADAPTER 24Vdc 2A 4Pin [: :] Molex USE
OPERATING TECH OTE-4824 AC ADAPTER 24Vdc 2A 4Pin [: :] Molex 5.5x5.5mm USED S4 100-240vac Used SWITCHING Adaptor Power Supply
Condition: Used - Works Great
Content : One Adapter only
• Manufacturer: OPERATING TECH / DEE VAN ELECTRONICSInc. (SHENZHEN) ITE
• Model: OTE-4824 S4
Compatible Model Number:
Compatible Model Number:
AZS 3968 OPERATING TECH OTE-60W-20 1 24060, OTE60W20, OTE60W201, cULus E170507
AZS3969 OPERATING TECH OTE-4824 S4, OTE4824 S4, cULus 9Z07 E168210
AZS3970 Globtek GT-81081-6024-T3, GT810816024T3, P/N.: TR9CI2500MLX-F, cULus 6D44 E170507
KRONOS 4500
L.P.S.
Compatible: cULus 6D44 E170507, 9Z07 E168210, 94XJ E174898
Efficiency Level V
•
Input: 100-240V~50/60Hz 1.3A 200VA
• [: :]Output: +24V === 2.5A LEVEL 3
• Connector Type: 4Pin Molex
• Pin size: 5.5 x 5.5 x 6.5 mm aprox
Pin1 = +ve 24vdc
Pin2 = -ve GND
Pin3 = -ve GND Earth
Pin4 = NC (No Pin)
• Dimension: 12 x 6 x 3 cm approx.
• Weight: 280 grams
To use With: Cable Modem etc.
INPUT
● Universal, 90 - 264Vac, 47-63 Hz, single phase.
● Inrush current:
❍ 30A Max @ 115Vac & cold start
❍ 60A Max @ 230Vac & cold start
OUTPUT
● Ripple *: 1 % p-p of output voltage measured
differentially
● Max total regulation **: 5 %
*Ripple voltage measurement is done with an oscilloscope
set at 20 MHz bandwidth and output terminated with 0.1 uF
ceramic capacitor and 47 uF aluminum capacitor at full
load
and nominal line
** includes line, load, temperature and set point
EFFICIENCY
● 75 % minimum
PROTECTION
● Output short circuit protected
● Over voltage protection
LEAKAGE CURRENT
● Less than 750uA
MECHANICAL
● AC socket IEC-320C14
● Output cord: 1.28 m
● Output connector: Barrel (center positive)
● Power ON LED indicator: Green
● Case Color: Black
● Dimensions (L x W x H), mm: 120 x 60 x 36
● Weight typical, g: 310
ENVIRONMENTAL
● Operating temperature: 0 to + 40 °C
(at full rated output power with natural
convection cooling and in non-restricted
environment)
● Storage temperature: -20 to + 85 °C
● Operating Humidity: 10 to 90 %
● Storage Humidity: 5 to 95 %
HI-POT TEST
● Primary to FG 1500Vac / 1 minute @ 10mA max
EMI COMPLIANCE
● FCC part 15J Class B
● CISPR 22 (EN 55022) Class B
SAFETY APPROVALS
● UL 1950 3rd Edition
● CSA C22.2 no 950
● TUV EN 60950
● CE Mark
