GLOBTEK GTM21097-4509-3.0 AC ADAPTER 6V DC 5A POWER SUPPLY
* CONDITION: NEW - WORKING
* CONTENT: ONE ADAPTER ONLY
* MANUFACTURER:GLOBTEK
* MODEL NO.:GTM21097-4509-3.0
* P/N # :TR9CB5000G05A-Y-MED ,TR9CB5000G05A-Y-M
* INPUT Voltage: 100-240V 1.6A MAX, 50-60HZ
* OUTPUT Voltage: DC 6V === 5A
* CONNECTOR TYPE: 5-PIN DIN FEMALE
* DIMENSION: 12 x 6 x 3.5 cm APPROX
* WEIGHT: 378g
* TO USE WITH: Medical equipement
Manufacturer's Specification:
INPUT VOLTAGE: 90 VAC TO 264 VAC
INPUT CURRENT: < 1.6 A RMS AT 90 VAC INPUT
INPUT FREQUENCY: 47 Hz - 63 Hz
INPUT CONFIGURATION:
GROUND PIN CONNECTED INTERNALLY BY AWG 18 STRANDED HOOK-UP WIRE, GREEN WITH YELLOW STRIPES JACKET, TO Y SAFETY CAPACITORS COMMON.
OUTPUT CURRENT: NO MINIMUM LOAD REQUIRED
OUTPUT POWER (RATED): 50 WATTS MAX
OUTPUT RIPPLE (PEAK TO PEAK): 1% OF OUTPUT VOLTAGE, PEAK TO PEAK, TYPICAL
OUTPUT REGULATION (LINE/LOAD): 5% MEASURED AT THE OUTPUT CONNECTOR
LINE REGULATION: 1% TYPICAL MEASURED AT FULL LOAD
TURN ON/TURN OFF OVERSHOOT: 5% MAXIMUM, 1 ms TYPICAL RECOVERY TIME FOR 25% STEP LOAD
TURN-ON DELAY: 1 SEC TYPICAL
HOLD-UP TIME: 10 ms TYPICAL AT NOMINAL INPUT VOLTAGE AND FULL LOAD
INRUSH CURRENT: 20 A TYPICAL AT 115 VAC INPUT AND 30 A TYPICAL AT 230 VAC INPUT
EFFICIENCY: 75% TYPICAL AT NOMINAL INPUT AND FULL LOAD
SWITCHING FREQUENCY: 100 kHz TYPICAL
OVER-VOLTAGE PROTECTION: VOLTAGE LIMITED TO LESS THAN 130%, CROWBAR METHOD
OVER-CURRENT/SHORT CIRCUIT: HICCUP MODE WITH AUTO-RECOVERY (110 - 130% OF RATED LOAD), HICCUP MODE OUTPUT WILL AUTORECOVER UPON REMOVAL OF SHORT
OTHER PROTECTION: INPUT LINE FUSING
SAFETY APPROVALS: UL 60601.1, CUL TO 22.2 NO. 601.1, TUV TO EN60601.1, PSE TO J60950 CB REPORT
DIELECTRIC WITHSTAND VOLTAGE: 5656 VDC (4000 VAC) FROM PRIMARY TO GROUND 2121 VDC (1500 VAC) FROM PRIMARY TO GROUND
LEAKAGE CURRENT: < 500 A at 264 VAC INPUT VOLTAGE
LINE SURGE: EN 61000-4-5 LEVEL 4
EMI: EN55011, Group 1, Class B, EN55022 Class B, EN55011, Group 1, Class B; EN55024 / EN60601-1-2 / IEC 61000-4-3:2002; EN55024 / EN60601-1-2 / IEC 61000-4-6:2001 ; EN55024/EN60601 -1-2/IEC 61000-4-8:2001; EN55024/EN60601-1-2 / IEC 61000-4-11:2001; EN55024 / EN60601-1-2 / IEC 61000-4-4:2001; EN55024/EN60601-1- 2/IEC 61000-4-2:2001; EN55024/EN60601-1-2 / IEC 61000-4-5:2001; EN55024/EN 61000-3-3 A1: 2001/EN 61000-3-3 A1: 2001; EN55024/EN 61000-3-2:2001 / EN 61000-3-2:2001. UNIT IS ELIGIBLE FOR CE MARK .
CE MARK: TESTED TO COMPLY WITH EN61000-3-2 EN610003-3 AND EN50082-1 INCLUDING EN61000-4-2 (SYSTEM LEVEL), EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11 LEVEL 4.
MTBF: GREATER THAN 200,000 HOURS AT 25C AMBIENT TEMPERATURE NOMINAL LINE AND FULL LOAD (MIL-217 STD)
OPERATING TEMPERATURE: 0C TO 40C AMBIENT TEMPERATURE
STORAGE TEMPERATURE: -40C TO 80C
HUMIDITY: 0% TO 90% RELATIVE HUMIDITY
Information's are here for your reference only and accuracy can not be guaranteed.
